세부사양 (SPECIFICATION) |
| 모델 |
M05 |
M10 |
M15 |
M I(20) |
M II(20) |
M30 |
M50 |
M100 |
| STANDARD LIFT |
2.5m |
2.5m |
2.5m |
3m |
3m |
3m |
3m |
3.5m |
| LOAD CHAIN |
6.3 x 19.1 |
6.3 x 19.1 |
7.1 x 21 |
7.9 x 23 |
6.3 x 19.1 |
7.1 x 23 |
9.0 x 27 |
9.0 x 27 |
| HAND CHAIN |
5.0 x 22.8 |
5.0 x 22.8 |
5.0 x 22.8 |
5.5 x 23.6 |
5.0 x 22.8 |
5.0 x 22.8 |
5.5 x 23.6 |
5.5 x 23.6 |
| NET WEIGHT |
11.0 kg |
11.5 kg |
13.8 kg |
21.6 kg |
17.0 kg |
23.0 kg |
41.0 kg |
78.0 kg |
| MIN DISTANCE |
315mm |
315mm |
340mm |
380mm |
380mm |
475mm |
635mm |
760mm |
| BETWEEN HOOKS |
| PULLING EFFORTS |
24 kg |
33 kg |
34 kg |
34 kg |
34 kg |
35 kg |
39 kg |
41 kg |
| TEST LOAD |
750 kg |
1,500 kg |
2,360 kg |
3,000 kg |
3,000 kg |
4,750 kg |
6,300 kg |
12,500 kg |
|
|
|
 |
